Slant Bed CNC Lathe ALTCK36A
Product Tags :
CNC lathe with bar feederCNC pipe thread lathe adoptsautomatic cnc lathe machinebar feeder cnc lathecnc lathecnc lathe 3 axiscnc lathe machinecnc lathe machine bar fedeercnc metal lathe machinehorizontal CNC lathe machine
Product Attributes :
ALMAZAKL CNC the slant bed CNC lathe offers high quality machining from heavy duty to high speed turning and milling machines with through hole diameters capable of machining small and large workpieces.
Product Description
Slant Bed CNC Lathe Processing Characteristics:
1. XZ axis linear guide rail ensures fast and accurate feeding;
2. The turret has 12 servo cutters, the drive milling cutter is optional, and the Y axis on the turret is optional;
4. The main axis C axis is optional, and the second main axis is optional;
5. Automatic feeding of tailstock sleeve;
6. Manual movement of standard tailstock, optional programmable tailstock;
7. The 30-degree bed design, together with the chain chip conveyor, provides an easy chip removal solution.
Almazakl cnc Slant bed CNC lathe with Y axis
The Main Technical Parameters
| Section | Item | ALTCK36A |
| The main parameters | Maximum upper turning diameter of bed | Φ360mm |
| Maximum machining diameter on tool post | Φ140mm | |
| Maximum processing length | 300 | |
| Spindle and chuck parameters | Spindle head type (optional chuck) | A2-5 |
| Spindle hole diameter | Φ48 | |
| Bar diameter | Φ41 | |
| Maximum stroke of tailstock | 200 | |
| Bed frame | Bed form and slope | Integral/45° |
| Shape | length * width * height (mm) | 2200×1600×1850 |
| Weight | Weight (approximate weight) | 2200kg |
