ALMAZAKL CNC CNC lathe machine is an economical and practical lathe with high quality and a wide range of applications. It is suitable for internal and external circles, tapers, arcs, threads, boring holes, oblique axes, and discs. It can also provide effective handling curves. You can choose the CNC system and accessories according to your requirements.
1.CNC lathe adopts high rigidity cast iron with high seismic strength;
2. ALMAZAKL CNC spindle heavy-duty cutting structure ensures high rigidity and high precision;
3.Flat bed CNC lathe electric turret, high positioning, fast tool change speed, high productivity;
4. The feed motor and the screw are directly connected, which can ensure the processing accuracy and positioning accuracy;
5.mini lathe can adopt hydraulic drive system to make the stroke longer and easy to operate;
6. The fully closed lid can protect the iron splash residue.;
ALCK6140x750 CNC Lathe Inspection ALMAZAKLCNC CNC lathes will be inspected
1.Automobile manufacturing: CNC lathes can be used to produce engine parts, steering systems, transmission systems, and other automotive parts.
2.Aerospace: CNC lathes can be used to manufacture aero-engine components, turbine blades, aircraft structures, and other complex parts.
3.Energy: CNC lathes can be used to make parts for generator sets, turbine parts, and other energy equipment.
4.Medical Devices: CNC lathes can be used to produce medical device parts such as surgical instruments and artificial joints.
5.Electronics: CNC lathes can be used to produce components for electronics, such as cell phone casings, cameras, and electronic connectors.
Item | Unit | ALCK6140X1000 |
Maximum turning diameter on the bed | mm | Φ400 |
top distance | mm | 750 |
Maximum turning diameter | mm | Φ400 |
Maximum turning diameter on the skateboard | mm | f220 |
Spindle hole diameter | mm | F52 |
Spindle speed range | rpm | 80-2200 |
Spindle maximum output torque | Nm | 480 |
Main motor output power | kw | 5.5 |
Z-axis rapid traverse speed | m/min | 8 |
X-axis travel | mm | 220 |
Z-axis travel | mm | 750 |
Tailstock sleeve diameter | mm | F65 |
Tailstock sleeve stroke | mm | 130 |
Boring bar diameter | mm | ф20 |
Machine size | mm | 2250×1400×1500 |
Machine weight | kg | 1500 |
